Efficient and Advanced Micro Vickers and Knoop Hardness Measurement with Bowers Premium Micro-Vickers Hardness Tester EW-110/A2 Series
The Motorised Turret with Analogue Measurement Microscope and Integrated Hardness Calculator offers an advanced, easy-to-use, and efficient solution for measuring Micro Vickers and Knoop hardness. The motorized turret, high-resolution analog eyepiece, built-in high-speed printer, and integrated hardness calculator make it an excellent choice for various applications, including quality control, research and development, and production environments.
Here are some features of Bowers Premium Micro-Vickers Hardness Tester EW-110/A2 Series:
- Fully automatic 4-position turret for Micro Vickers /Knoop measurements
- Choice of turret configuration
- 3 objectives and 1 indenter
- 2 objectives and 2 indenters (Vickers & Knoop)
- Dual indenter (Vickers/Knoop) turret optional - High-resolution analog eyepiece 15x
- Built-in high-speed printer
TECHNICAL SPECIFICATION
| Technical Specification | |
|---|---|
| Test force selection | Manual |
| Test procedure | Automatic - loading/dwell/unloading |
| Hardness value | 5 digits |
| Turret | 4 positions over 360º - fully automatic - memorised start position - �option for 2 indenters and 2 objectives or 1 indenter and 3 objectives |
| Test force accuracy | < +/-1% for force from 100gr to 2kg - < +/-1.5% for force below 100gr |
| User display | Length of diagonals - hardness value - converted value - test force - online statistics |
| Display resolution | 0.1 HV - HK |
| Standardisation | EN ISO 6507 - ASTM E-384 - EN ISO 4545 |
| Statistics | Total test - max - min - average - range - standard deviation all in real time after each test |
| Control panel | Start test - stop test - light intensity - dwell time - print - clear |
| Firmware | English |
| Memory | Memory for 20 test results with CCD-VIEW software unlimited results |
| Data output | RS-232 Bi-Directional |
| Dwell time setting | Default 5 seconds - user defined 1 to 60 seconds (5 sec. increments) |
| Printer | Built in silent high speed thermal printer |
| Eyepiece microscope | Bright dual line filar eyepiece with 15x magnification - 0.1µm reading |
| Light source | Halogen 12V - 30W - green filter - dimmable |
| Optical path | 2 way - eyepiece / camera |
| Vertical capacity | 90mm (maximum specimen height) |
| Horizontal capacity | 120mm (from centre line) |
| Stage dimensions | 100x100mm - travel 25x25mm - and reading 0.01mm |
| Operating temperature | 5ºC to 40ºC (+/-20º for force 25gr and 50gr) |
| Humidity | 10% to 90% non condensing |
| Dimensions | 420 x 250 x 490mm |
| Weight | 37.5Kg |
| Power | 240V/110V - 50/60Hz - single phase |
